Specifications

PRICING

Price

Standard

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Air
Engine - Valves	2
Engine - Valves Per Cylinder	2
Engine - Valve Configuration	SOHC
Engine - Bore (mm)	47
Engine - Bore (in)	1.85
Engine - Stroke (mm)	41.4
Engine - Stroke (in)	1.63
Engine - Displacement (cc)	72
Engine - Displacement (ci)	4.4
Engine - Compression Ratio	9:1
Engine - Starter	Kick
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	13
Carburetion - Carburetion Type	Carburetor

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual / Automatic Clutch
Transmission - Number Of Speeds	3
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Wheelbase (in)	42
Dimensions - Wheelbase (mm)	1066.8
Dimensions - Ground Clearance (in)	7
Dimensions - Ground Clearance (mm)	177.8
Weight	Standard
Weight - Dry Weight (lbs)	128
Weight - Dry Weight (kg)	58.1
Capacities	Standard
Capacities - Fuel Capacity (gal)	1.5
Capacities - Fuel Capacity (l)	5.7
Capacities - Fuel Capacity Reserve (gal)	0.3
Capacities - Fuel Capacity Reserve (l)	1.1
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.56

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Fork Guards	Yes
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Light Guard	No
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Suspension Size (in)	1
Front Suspension - Front Suspension Size (mm)	27
Front Suspension - Front Travel (in)	3.2
Front Suspension - Front Travel (mm)	81.3
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	3.5
Rear Suspension - Rear Travel (mm)	88.9
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	No
Rear Suspension - Rear Adjustable Rebound Damping	No
Rear Suspension - Number Rear Shock Absorbers	1

WHEELS & TIRES

Wheels	Standard
Wheels - Front Wheel Width (in)	2.5
Wheels - Rear Wheel Width (in)	3
Tires	Standard
Tires - Front Wheel Diameter	14
Tires - Rear Wheel Diameter	12
Tires - Front Tire (Full Spec)	2.5 X 14
Tires - Rear Tire (Full Spec)	3 X 12

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Drum
Brakes - Rear Brake Type	Drum

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	26.1
Seat Specifications - Seat Height (mm)	662.9
Seat Specifications - Number Of Seats	1
Seat Backrest - Backrest Logo Plate	No

PAINT & FINISH

Paint

Standard

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
