Specifications

PRICING

Price	Standard
Price - MSRP	3599
Price - Currency	US Dollars
Price - MSRP + Destination	3599

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Air
Engine - Valves	2
Engine - Valves Per Cylinder	2
Engine - Valve Configuration	OHV
Engine - Bore (mm)	65
Engine - Bore (in)	2.56
Engine - Stroke (mm)	59
Engine - Stroke (in)	2.32
Engine - Displacement (cc)	196
Engine - Displacement (ci)	12
Engine - Compression Ratio	9.2:1
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Carburetion Brand	Mikuni
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	22
Carburetion - Carburetion Type	Carburetor
Snorkel Air Intake	Standard

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Continuously Variable (CVT)
Transmission - Overdrive	No
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Primary Drive (Engine / Transmission)	Belt
Transmission - Reverse	Yes
Transmission - Transmission Brand	Polaris Variable Transmission (PVT)
Transmission - Hi / Low Range	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	65
Dimensions - Length (mm)	1651
Dimensions - Width (in)	42
Dimensions - Width (mm)	1067
Dimensions - Height (in)	42
Dimensions - Height (mm)	1067
Dimensions - Wheelbase (in)	45
Dimensions - Wheelbase (mm)	1143
Dimensions - Turning Radius (ft)	5.4
Dimensions - Ground Clearance (in)	5.7
Dimensions - Ground Clearance (mm)	145
Dimensions - Length (ft)	5.42
Dimensions - Length (ft/ft)	5
Dimensions - Length (ft/in)	5
Weight	Standard
Weight - Dry Weight (lbs)	395
Weight - Dry Weight (kg)	179
Weight - Payload Capacity (lbs)	215
Weight - Payload Capacity (kgs)	98
Weight - Towing Capacity (lbs)	300
Weight - Towing Capacity (kgs)	136.1
Capacities	Standard
Capacities - Fuel Capacity (gal)	2.5
Capacities - Fuel Capacity (l)	9.5
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.5

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Floor Boards	Standard
Floor Boards - Floor Board Location	Driver
Hand Grips	Standard
Exterior Guards	Standard
Exterior Guards - Brush Guard	No
Exterior Guards - Light Guard	No
Front Fender	Standard
Rear Fender	Standard
Handlebars	Standard
Front Bumper	Standard
Rear Bumper	Standard
Skid Plate	Standard
Skid Plate - Bash Plate (Front)	Yes
Skid Plate - Full Length Skid Plate	Yes
Safety Flag	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Double A-Arm
Front Suspension - Front Travel (in)	7
Front Suspension - Front Travel (mm)	178
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Steering Damper	No
Front Suspension - Front Stabilizer Bar	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Swing Arm
Rear Suspension - Rear Travel (in)	6.5
Rear Suspension - Rear Travel (mm)	165
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	No
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Material	Steel
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Steel
Wheels - Front Tire Diameter (in)	21
Wheels - Rear Tire Diameter (in)	20
Tires	Standard
Tires - Tire Brand	Duro
Tires - Front Tire Width	7
Tires - Front Wheel Diameter	10
Tires - Rear Tire Width	10
Tires - Rear Wheel Diameter	9
Tires - Front Tire (Full Spec)	Duro: 21 X 7-10
Tires - Rear Tire (Full Spec)	Duro: 20 X 10-9

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Drum

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	32
Seat Specifications - Seat Height (mm)	813
Seat Specifications - Number Of Seats	1
Seat Backrest - Backrest Logo Plate	No
Seat Backrest - Lumbar Adjustment	No

INSTRUMENTATION

Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Light

STORAGE

Hard Side Cases - Number Of Side Cases	0
Saddle Bag(s) - Number Of Saddle Bags	0
Cupholder - Number Of Cupholders	0
Storage Cover - Camouflage Trim	No

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Windshield - Height Adjustable	No
Windshield - Tinted	No

CONVENIENCE

Heated Hand Grips - Adjustable	No
Hand Muffs - Heated	No

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

AUDIO & COMMUNICATION

Radio - Satellite	No
Speakers - Number Of Speakers	0
CD Player - Number Of Discs	0

DRIVE LINE

Driveline	Standard
Driveline - Driveline Type	4X2
Driveline - Number Of Driveline Modes	1
Driveline - Rear Unlocking Differential	No
Driveline - Rear Solid Axle	Yes

STEERING

Steering	Standard
Steering - Steering Type	Manual
Steering - Steering Control	Handlebar

TOWING & HAULING

Draw Bar

Standard

YARD EQUIPMENT

Plow - Adjustable

No

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
